8310
Series
Automatic Operator Actuators & Accessories
Auto Operator
Actuators &
Accessories

4-3/4˝ Square Surface
and Flush Mounts
8310-853 8310-853T
Wall Mounted Actuator Wall Mounted Actuator
n Hardwired low voltage actuator with stainless steel touch plate in 4-3/4˝ n Same as the 8310-853, with the
(121mm) square added engraving of “Push to
n Engraved blue filled handicap symbol conforms to most accessibility codes Open”
n Designed to mount in a flush or surface mount box (sold separately) in/on a
vertical surface near the controlled door
n Optional mounting in single gang electrical box (by others) or double gang
box (4˝ x 4˝ by others) or on an 8310-866 bollard post
n Heavy industrial grade components provide vandal resistant mounting and
weather resistant switch standard

8310-853WP 8310-853TWP 8310-867F
Surface Mounted Actuator Surface Mounted Actuator Flush Mount Box
n Wireless, low profile, low voltage actuator with square, stainless steel touch n Same as the 8310-853WP, with n Rugged Plastic Box
plate in 4-3/4˝ (121mm) square the added engraving of “Push to
Open” n 4-3/4˝ Square
n Engraved blue filled handicap symbol conforms to most accessibility codes
n Optional accessory - can be used
n Surface mount box includes integral transmitter w/ battery and actuator w/ any 4-3/4˝ square actuator
switch
n Heavy industrial grade components provide vandal resistant mounting and
weather resistant switch standard
n Requires 8310-865 Receiver

8310-867S 8310-801
Surface Mount Box Weather/Trim Ring
n Rugged Plastic Box, 4-3/4˝ n Plastic Weather Ring,
Square 4-3/4˝ Square
n Optional accessory - can be used n Optional accessory - can be used
w/ any 4-3/4˝ square actuator w/ any 4-3/4˝ square plastic
mounting box

8310-844 8310-865 8310-813
Transmitter Receiver Touchless Wall Mounted Actuator
n Wireless, 1 Channel, 9v battery n Wireless, 1 Channel, w/ n Hardwired low voltage actuator with plastic plate in 4-3/4˝ (121mm)
included Sequencing Feature square
n Use to convert standard wall n Used in conjunction w/ Wireless n Optional mounting in single gang electrical box (by others) or double gang
mount actuator to wireless Actuators & Transmitter(s) box (4˝ x 4˝ by others)
n Requires 8310-865 Receiver

G121
