Page 389 - Herrajes Patricios - Catalogo LCN

8310
Series

Auto Operator
Actuators &
Accessories

36˝ x 6˝ Full Length
Actuators

Automatic Operator Actuators & Accessories

8310-836T 8310-836TW 8310-865
Full Length Actuator (FLA) Flush Length Actuator (FLA) Receiver
n Hardwired low voltage actuator with stainless steel touch plate with 36˝ x n Same as the 8310-836T with a n Wireless, 1 Channel,
6˝ activation surface built in wireless transmitter and w/Sequencing Feature
3v battery
n Blue handicap symbol conforms with most accessibility codes n Used in conjunction w/ Wireless
n Use in conjunction with 8310-865 Actuators & Transmitter(s)
n Added “PUSH TO OPEN” lettering for enhanced identification
Receiver (not included)
n Designed to meet California building codes and increase accessibility for
wheelchair bound entrants
n Can easily be mounted to any flat surface or a bollard post

8310-844 8310-866FLA 8310-3836T 8310-3836TW
Transmitter FLA Bollard Post FLA Bollard Mount Kit FLA Bollard Mount Kit
n Wireless, 1 Channel, 9v Battery n A powder coated steel 42˝ x 4˝ x n 36˝ x 6˝ Actuator with 8310- n 36˝ x 6˝ Actuator with 8310-
included. 6˝: Bollard Post, mounting base 866FLA Bollard for wired 866FLA Bollard and 8310-844
n Used to convert standard pre prepped for the 8310-836T applications wireless Transmitter
actuators to wireless n Includes 8310-866 CAP, 2 n Transmitter requires 8310-865
mounting screws & spacer for Receiver (not included)
n Requires 8310-865 Receiver
installation
n Recommended for exterior
application with 8310-836T
n Used with the 866FLA bollard
post

G125
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
