8310
Series

Auto Operator
Actuators &
Accessories

1-1/2˝ x 4-3/4˝ Surface
and Flush Mounts
NOTE: LCN recommends for all jamb mount actuators be used on an interior installation only.

Automatic Operator Actuators & Accessories

8310-818 8310-818T
Jamb Mounted Actuator Jamb Mounted Actuator
n Hardwired low voltage actuator with rectangular stainless steel touch n Same as the 8310-818, with the
plate. added engraving of “Push to
n 1-1/2˝ (38mm) wide by 4-3/4˝ (121mm) Open”
n Engraved blue filled handicap symbol conforms to most accessibility codes
n Designed to mount in a frame cutout (template provided) projecting
approximately 1/2˝ (12mm) from the frame
n Optional mounting in surface or flush mount box (sold separately)
n Heavy industrial grade components provide vandal resistant mounting and
weather resistant switch standard

8310-819F 8310-819S 8310-844J 8310-865
Flush Mount Box Surface Mount Box Transmitter Receiver
n Rugged Plastic Jamb Box n Rugged Plastic Jamb Box n Wireless, 1 Channel, Jamb Mount, n Wireless, 1 Channel, w/
n 1- 1/2˝ x 4-3/4˝ rectangle, n 1-1/2˝ x 4-3/4˝, rectangle 3v battery included Sequencing Feature
optional accessory - can be used n Optional accessory - can be n Used to convert standard jamb n Used in conjunction w/ Wireless
w/ any 1-1/2˝ x 4-3/4˝ jamb used w/ any 1-1/2˝ x 4-3/4˝ mount actuator to wireless when Actuators & Transmitter(s)
mount actuator used w/ 819F or 819S boxes.
jamb mount plastic mounting
box Requires 8310-865 Receiver
(interior use only)

G119
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
