Typical
Pneumatic
Powered
Systems

These pages illustrate examples of typical Pneumatic LCN systems. Please consult your local SSC representative or LCN for assistance
with specific installations and material requirements.

Pneumatic Pneumatic
Auto-Equalizer Tubing 12V DC Auto-Equalizer Tubing
(100' Max.) Wiring (50' Max.)
Receiver
120V AC
Input
Control
Box 120V AC
Input
Interior Pneumatic Interior
Actuator Tubing Actuator Control
(500' Max.) Box
120V AC
Input
Exterior Exterior
Actuator Actuator
Compressor

ALTERNATE VESTIBULE DOOR SYSTEM (WIRED) VESTIBULE DOOR SYSTEM (WIRELESS)
n Slow opening automatic doors with sequential operation for n Slow opening automatic doors with sequential operation for
exterior and vestibule pairs of doors single exterior and vestibule doors
n No guide rails or safety devices n No guide rails or safety devices

How It Works: How It Works:
n People requiring assistance press exterior actuator for entry n People requiring assistance press exterior actuator for entry
n The exterior pair opens and after a short sequential delay the n The exterior door opens and after a short delay the interior door
interior pair opens opens
n As the system times out, first the exterior, then the interior n When the system times out, first the exterior, then the interior
doors close door closes
n Pressing the interior actuator reverses the process to exit the n Pressing the interior actuator reverses the process to exit the
building building
n This allows passage through the vestibule without all doors n This allows passage through the vestibule without both doors
open for the entire cycle open for the entire cycle
n If a person stops in the vestibule and the system times out n If a person stops in the vestibule and the system times out before
before they exit, pressing either vestibule actuator opens the they exit, pressing either vestibule actuator opens the appropriate
appropriate doors door
n Compressor is sized for multiple systems. Sequential n Sequential operation is not recommended with scanners or
operation is not recommended with scanners or motion motion sensors
sensors n If not actuated, the Auto Equalizer functions as a full featured
n If not actuated, the Auto Equalizer functions as a full feature door closer
door closer
Bill Of Materials: Qty. Part No. Description Bill Of Materials: Qty. Part No. Description
2 4822 Auto Equalizer (exterior) 1 4822 Auto Equalizer (exterior)
2 4811 Auto Equalizer (interior) 1 4811 Auto Equalizer (interior)
1 7902S Control Box with 1 7982S Control Box with
Sequencer Card Sequencer Card
1 Compressor* 4 8310-3856WS RF Actuators
4 8310-856 Actuator 2 8310-865 RF Receiver
(as needed) 925 Tubing (as needed) 925 Tubing
* Contact Technical Support to verify compressor requirements.
