Typical
Pneumatic
Powered
Systems

These pages illustrate examples of typical Pneumatic LCN systems. Please consult your local SSC representative or LCN for assistance
with specific installations and material requirements.

Pneumatic Pneumatic
Auto-Equalizer Tubing 12V DC Auto-Equalizer Tubing
(100' Max.) Wiring (50' Max.)
Receiver
120V AC
Input
Control
Box 120V AC
Input
Interior Pneumatic Interior
Actuator Tubing Actuator Control
(500' Max.) Box
120V AC
Input
Exterior Exterior
Actuator Actuator
Compressor

SINGLE INTERIOR DOOR SYSTEM (WIRED) SINGLE INTERIOR DOOR SYSTEM (WIRELESS)
n Slow opening interior door leaf n Slow opening automatic door on door leaf
n System may be expanded to include an additional n Wireless actuators
simultaneous door n Stand alone system, no planned expansion
n No guide rails or safety devices n No guide rails or safety devices
How It Works: How It Works:
n A person requiring assistance triggers the system using either n A person requiring assistance triggers the system using either
actuator. actuator
n The control box supplies pressurized air to the Auto Equalizer n The wireless transmitter in the actuator sends a signal to the
which opens the door slowly to 90˚, holds it for up to 30 wireless receiver which triggers the control box
seconds, then applies full spring power to reliably close and n The control box supplies pressurized air to the Auto Equalizer
latch the door which slowly swings door to 90°, holds it for up to 30 seconds,
n If not actuated, the Auto Equalizer functions as a full featured then applies full spring power to reliably close and latch the
door closer door.
n If not actuated, the Auto Equalizer functions as a full featured
Bill Of Materials: Qty. Part No. Description
1 4811 Auto Equalizer door closer
1 8310-856 Actuator (exterior) Bill Of Materials: Qty. Part No. Description
1 8310-856 Actuator (interior) 1 4811 Auto Equalizer
1 7901 Control Box 2 8310-3856WS Wireless Actuator
1 Compressor* 1 8310-865 Wireless Receiver
(as needed) 925 Tubing 1 7981 Control Box
(as needed) 925 Tubing
* Contact Technical Support to verify compressor requirements.
