Pneumatic
Powered
Systems

PNEUMATIC (AIR) POWERED SYSTEMS n Hazardous Location Use
LCN Pneumatic Auto Equalizer systems use the power of pressurized air Since there is no high-voltage wiring at the door frame, pneumatically
to do the work of automatically opening the door. These systems have powered systems are ideal for use in hazardous areas. The control
exceeded 3 million full load automatic operating cycles; that’s 10 times box, which contain the valves and electrical timing circuits, is remotely
the industry standard! A basic pneumatic system consists of an automatic located outside the hazardous area.
operator to provide the door control, a control box that contains the n Blow-Open (Smoke Evacuations Systems)
valves and electrical timing circuits, actuators to start the system, and a An auxiliary “blow-open” box is available and is controlled by the
compressed air source. building smoke evacuation system to allow fresh air into the building.

UNIQUE FEATURES When activated, the normal pneumatic power operator functions are
not available. The 7949 Series “blowopen” box works with or without
n Multi-Door & Single-Door Solutions the 7900 Series control boxes. (Limited to 50 linear foot of tubing).
The pneumatic automatic operators are ideal for multidoor
applications because the cost per door leaf decreases significantly as STANDARDS, LISTINGS & APPROVALS
the number of door leaves increase. A single control box may power up n UL listed for self-closing doors without hold open under “SWINGING
to two pairs of doors simultaneously making it a cost-effective solution DOOR CLOSERS (GVEV)” file R1943.
for single or multi-door applications. This flexibility results in significant
savings in material and installation costs. n Tested and certified under ANSI Standard A156.19. Refer to Section 2.1
and consult factory for details.
n Quiet Operation
Since the pneumatic automatic operators are powered by pressurized n ANSI Standard A117.1, Section 4.13.13.
air, they are quiet, efficient, and very reliable. Flexible LCN pneumatic n ADA law, Section 4.13.12.
tubing is the only connection between the control box and the door n UL 10B and UL 10C listing.
frame. There is no need for high-voltage wiring at the door frame since n Consult the factory for other listings
all of the power for operation is generated by pressurized air located
away from the door frame. (Note: special fittings are available so 3/16˝ WARRANTY
metal tubing (by others) can be used in fire rated plenums). n 2 year limited warranty. See General Information Section for complete
n Pneumatically (Air) Powered details.
All pneumatic automatic operators require a compressed air source.
LCN’s pneumatic systems have the flexibility to run as an independent STANDARDS, LISTINGS & APPROVALS
unit (7980 Series has a compressor built into the control box) or to n Operators mounted according to the LCN installation instructions
run off an existing air supply (7900 Series has connections for utilizing require no periodic maintenance or adjustments.
existing air supply). Using a self-contained 7980 Series control box n Periodic visual inspections are recommended.
for single or double door leaf applications eliminates the need for an n Inspect and service filter assembly in 7900 Series control boxes as
independent compressor. Existing building air compressors with a required.
storage tank can be used to reduce the cost of multi-door systems and
must utilize the 7900 Series control boxes. n No service contracts.
n Easy Adjustment/Installation
The air pressure and timing cycle are easily adjustable to meet the
need of a specific installation. Because the control box can be located
anywhere within 100 linear tubing feet from the controlled door for the
7900 Series or within 50 linear tubing feet for the 7980 Series, they can
be placed in easily accessible locations. Convenient features such as
sequential operation of vestibule doors are available.
n Multiple Mounting Configurations
Available in three different mounting configurations:
- Concealed in the frame (2610 Series).
- Top Jamb Surface Mounted on the pull side of the door (4810 Series).
- Top Jamb Surface Mounted on the push side of the door
(4820 Series).
- Door Mounted, Parallel Arm on the push side of the door
(4840 Series).

G7
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
