4510T
Series

Accessories

Cylinder Cover Arms

4511T(3)(4) 4510T-72MC 4510T-3077T
Cylinder Assembly Metal Security Cover Standard Security Arm
n Handed n Handed n Handed
n Cast iron n Four point TORX mounting for n Solid forged steel, large cross section arm
n Standard extra security n Special threaded attachment of track roller
n Closer adjustments not for potentially abusive installations
accessible with cover installed n Double slab arm/pinion attachment for
maximum strength
n Can only be used with high security track
roller, 4510T-3034

Track

4510T-3038 4510T-3034
Security Track Security Track Roller
n Non-handed n Low friction track roller threads
n Designed to eject foreign into 4510T-3077T arm for extra
objects placed in track during strength and security
either opening or closing n Can not be removed without
motion disconnecting arm from closer
n Requires track roller,
4510T-3034

Installation Accessories

4510T-18
Plate
n Required where top rail is less
than 3 3/4˝ (95 mm)
n Requires minimum 2˝ (51 mm)
top rail

F21
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
