ELECTRONIC ACCESS CONTROL COMPONENTS ACCESSORIES
C400 DESKTOP CONSOLES
—

An economical method of Features
controlling 1−2 doors. . Choice of heavy duty
momentary or maintained
DORMA desktop consoles are operating switches
available in two switch configura- accommodate lock control
tions with tricolor LED indicators. functions.
When used with a door position . Tricolor LED indicators provide
or a lock status sensor, the LEDs for immediate status indication
allow monitoring of door and lock of door position or lock status
modes. The switches can provide when used with lock monitors
an on/off function or momentary such as door position (DPS) or
access control for electromag- bond sensors (BA).
netic locks, shear locks, bolt . Push-button switches provide
locks, delayed egress systems, an aesthetically pleasing
electrical exit systems, or electric appearance and high Available Items
strikes. operational reliability.
Item Description
. The CC-401DTM has (1) LED Specifications CC401DTM 1 Momentary (MO) switch, 1 LED
and (1) momentary switch to . Dimensions: 4-1/8" W × 3-1/8" CC402DTM 2 Momentary (MO) switches, 2 LEDs
release and monitor one door H × 6-1/4" L. Contact Rating: CC403DTM 1 Momentary (MO) switch, 1 maintained (MA)
opening. 5 A @ 30 VDC max. switch, 2 LEDs
. The CC-402DTM has (2) LEDs . Input Power: 12/24 VDC @ 20
CC402DTMA 2 Maintained (MA) switches, 2 LEDs
and (2) momentary switches to mA required for each LED.
release two door openings. . Console Color: Beige.
. The CC-403DTM has (2) LEDs
with (1) momentary switch and Switch Wiring
(1) maintained switch. . Common: White.
. Normally Open (NO): Yellow.
The momentary switch can be . Normally Closed (NC): Orange.
used to release a single door. The . Indicator: Bicolor LED 12 to 24
. V. Negative: Black.
maintained (On/Off) switch can
be used as a bypass for keeping . Red Illumination Positive: Red
the door unlocked for an . Green Illumination Positive:
extended period of time. The Green.
tricolor LEDs can display green, . Amber Illumination Positive:
red, and amber colors to indicate Power red and green
up to three lock status simultaneously.
conditions.

48 DORMA
