ELECTRONIC ACCESS CONTROL COMPONENTS ACCESSORIES
DESK SWITCHES
—
PD15-1—MA SPDT 6 A @ 3909 Rocker Switch—Suitable
30 V AC/DC for desk mount applications.
PD15-2—MO SPDT 10 A @ Surface mount under desk or
30 V AC/DC counter for concealment.
PD15-3—MO SPDT push-button, Available in molded beige.
with on/off toggle switch 6 A @ 30
V AC/DC 09SMO—1 MA SPDT, 10
A @ 250 V
Mounted on the underside of a 09SMA—1 MA SPDT, 10
desk for remote door control. May A @ 250 V
be connected to REX input of an
access control or trigger input of a
time delay relay to allow timed MC-4—Self-locking recessed
access and egress. mount. 3/4" dia. magnetic contact.
Accommodates up to a 1/2" gap
between the door and frame.
Adjustable ball type door position
switches. Compatible with SPDT 250 mA @ 30 V AC/DC,
swinging or sliding doors. #22 AWG
DPS-11—SPDT 5 A @ 30 V AC/
DC, #20 AWG
DPS-11-2—(2) SPDT 5 Amp @ 30
V AC/DC, #20 AWG MC-7—Self-locking recessed
mount with 1" dia. magnetic
Finish contact.Accommodates up to a
Aluminum: 628 (Satin) 1/2" gap between the door and
frame.
SPDT 250 mA @ 30 V AC/DC,
#22 AWG
39043 Emergency Pull Station—
Enables emergency release for
electromagnetic locks. Clear MC-4M—Recessed magnet
polycarbonate cover lifts easily so mounted on 1-1/4" × 4-7/8" plate.
paddle can be pulled forward, Accommodates up to a 1/2" gap
instantly releasing lock. Available between the door and frame.
in molded yellow or blue with red
pull. SPDT 250 mA @ 30 V AC/DC,
#22 AWG
043—1 MA DPDT, 6 A @ 125
VAC Finish
Aluminum: 628 (Satin)
DORMA 49
