4000 Series
surface
mounted
closers

APPLICATIONS FINISHES
n For aluminum, hollow metal, or wood swinging doors and frames. n Available in six standard or optional custom powder
n Can be used with hinge or pivot mounted door. coat finishes to blend with door and frame.
n Adapter plates and other installation accessories available for n LCN’s powder coat finishes surpass 100 hours of salt spray which
unusual conditions. is over four times the ANSI standard for corrosion resistance.
n For installations where a higher level of corrosive resistance is
FEATURES COMMON TO 4000 SERIES required, LCN offers an optional special rust inhibiting (SRI) pre-
n Each closer (except 4050, 4050T, 4040XP, 4040XPT, 4030, 4030T) treatment. Closers that combine the exclusive LCN powder coat finish
is designed for a specific mounting; hinge side, top jamb, or parallel and the SRI pre-treatment exceed the ANSI standard for corrosion
arm. 4040XP closer with regular or hold-open arm mounts hinge side resistance even further.
or top jamb. 4030, 4040XP and 4050 regular parallel arm closers n Plated finishes are available as an option to accent door and frame.
include 62PA SHOE required to parallel arm mount either regular or (SRI not available with plated finishes).
hold-open arm. LISTINGS & APPROVALS
n Handed for right or left swinging doors, except for 4000T, 4030,
4030T, 4040XP, 4050, 4050T and 4040XPT. UL listed for self-closing doors without hold-open under “SWINGING DOOR
n Closers to meet ADA reduced opening force requirements CLOSERS”(GVEV) file R1943.
except 4000T. Tested and certified under ANSI Standard A156.4 Grade One. Consult
n Adjustable hydraulic backcheck cushions opening swing prior to 90°. factory for details.
n Separate regulation of general closing speed and latching speed. Consult factory for other listings such as; cUL, California State Fire Marshal,
n Joints in regular arm and shoe adapt to uneven trim. Bureau of Standards and Appeals.
n Reversible shoe to boost latching power on double lever arms.
n Available in a wide range of standard or optional custom powder POSITIVE PRESSURE
coat finishes to blend with door and frame. LCN closers have been certified for three hours by UL to be in compliance
n Plated finishes available to accent door and frame. with UL 10C. Contact LCN for specific details on door closer fire ratings.
n Not designed for exterior mounting or exposed to elements. FASTENERS
DESIGN ASSISTANCE 4010, 4010T, 4020, 4020T, 4040XP, 4040XPT, 4050, 4050T, 4110, 4110T
LCN has been providing reliable solutions to unique door control Series closers are shipped with: A standard SELF-REAMING and TAPPING
problems since 1925. Design and specification assistance are SCREW (SRT) pack that contains Philips head SRT screws to install the
only a phone call away. closer. 4000T series closers are shipped with: A standard WOOD and
MACHINE SCREW (WMS) pack that contains Philips head wood and
Contact LCN for assistance or technical information at 877-671-7011 machine screws to install the closer. 4030, 4030T series closers are shipped
or FAX 800-248-1460 (Order Entry), Fax 815-879-1495 for with: A standard WOOD and SELF-TAPPING MACHINE SCREW (WMS)
Product Support. pack that contains Phillips head wood and self-tapping machine screws to
WARRANTY install the closer.Standard LCN thru bolts (TB) can be installed on 1-3/4˝
30 year limited warranty; 25 year limited warranty (4050). See General (44 mm) thick doors with 1/4-20 machine screws. Optional thru bolt (TB)
Information Section for complete warranty details. sizes are available for 1-5/8˝ (41 mm) or 1-3/8˝ (35 mm) door thickness,
but this must be specified when ordering.
SPECIFICATIONS
Refer to “SPECIFICATIONS” section for suggested architectural
specifications.
MATERIALS
n High strength cast iron or cast aluminum (4050) cylinder. Drill 25/64˝ for
n Forged steel main arms. steel doors
n One piece forged steel piston. or
Drill 3/8˝
n Double heat treated pinion. for wood doors
n LCN’s all weather “Liquid X” fluid performs to temperature
ranges from 120°F (49°C) to -30°F (-35°C) without any seasonal Notes:
adjustment. 1. For Thru Bolts, specify door thickness if other than 1-3/4˝ (44mm),
represented in diagram as dimension "X".
n High efficiency, full complement, low friction bearings. 2. Phillips head, metric machine screws are available, please specify.
n Tamper resistant regulating screws. 3. LCN recommends the use of wood screws, available in optional WMS screw packs,
n Full rack and pinion hydraulic action. for wood door applications.
n Quiet, low friction track and roller combination for all single lever arm MAINTENANCE
(track style) closers.
Closers mounted according to LCN installation instructions require no
periodic maintenance or adjustments.

B2 LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
