9140
Series
Benchmark

Accessories

Motor Gearbox Control Box

9140-3454S 9140-3454 9130-3462
Motor Gearbox Assembly Motor Gearbox Assembly Control Box (120v)
(W/O Switch)
n Driving mechanism for operator n Electronic controlling device
(switch included) n Driving mechanism for with power supply output
n For 27˝ unit operator (switch not and power boost feature for
included) Benchmark
n For full length unit (36˝)
Brackets

9140-3018 9140-3351-1
Mounting bracket Switch Bracket
n Standard n 29˝ cable
n Used with a 36" door
n Used to locate switch at end of
cover on full length unit
Covers

9140-72MC 9140-72FC 9140-163
Metal Cover Full Metal Cover Cover Insert
n Non-handed n Non-handed n Used to cover operator shaft
opening (includes 2 pieces)
n 27˝ n 36˝
n Extruded aluminum cover n Extruded aluminum cover
n Standard

9140-163-1 9140-334
Cover End Cap Insert Cover End Cap
n Used to cover switch hole n Black plastic
opening n Includes 9130-163-1 cover and cap insert

G63
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
