4110T
Series

How-to-order 4110T Series closers Ordering Information
Closer will be shipped with:
1. Specify cylinder size - Standard cover
4111T (ADA) - Standard arm
4113T - Track roller
4114T - Standard track
- Self-reaming and tapping screws
2. Specify hand unless options listed below are selected.
RH
LH

3. Select finish
Standard Powder Coat __________
Aluminum, Dark Bronze, Statuary, Light Bronze, Black, Brass

Closer options

Cover Specify Track Installation Accessories
Metal (MC) Standard with Bumper (BUMPER) Plate, 4110T-18
Hold-Open (HO)
Finish Hold-Open with Bumper (HBUMPER) Special Template
Custom Powder Coat (RAL) ___________ ST- _________
(handed metal cover required) Specify Screw Packs
Plated Finish, US ______________ TB* w/Self-Reaming and Tapping (TBSRT)
(handed metal cover required) Wood & Machine Screw (WMS)
SRI primer (use with powder coat finishes only) TB*, Wood & Machine Screw (TBWMS)
TORX Machine Screw (TORX)
TB* & TORX Machine Screw (TBTRX)
* Specify door thickness if other than 1-3/4˝.
Table of sizes

n Select closer based on width of door
n Sized 4110T series cylinders available in size 1, 3 or 4
n Closing power of all 4110T Series closers may be increased 15%
n Specify next higher size closer where strong drafts exist

Interior door width

26˝ 34˝ 38˝ 48˝
660mm 864mm 965mm 1219mm
size 1 size 3 size 4
4113T
4114T
Minimum door width
Indicates recommended range of door width for closer size.

Reduced opening force 4110T Series closers
CAUTION ! Any manual door closer, including those certified by BHMA to conform to ANSI Standard A156.4, that is selected, installed and adjusted based
on ADA or other reduced opening force requirements may not provide sufficient power to reliably close and latch a door.
Refer to POWER OPERATORS section for information on DOOR WIDTH 36˝ 42˝ 48˝
systems that meet reduced opening force requirements
without effecting closing power. 8.5* lbs. N/A N/A N/A
5.0* lbs. 4111T 4111T 4111T
* Maximum opening force.

LCN Door Control Catalog B83
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
