4110T
Series

Accessories

Installation Accessories

4110T-18 4110T-169 4110T-3054 4110T-3034
Plate Track Bumper Hold-Open Clip Track Roller
n Required where top rail, when n Mounts in track to assist n Mounts in track to provide hold- n Quiet, low friction roller
measured from the stop, is less backcheck, not replace auxiliary open function assembly
than 5-1/4˝ (133 mm) stop n Hold-open point controlled by clip n Shoulder dimension “X” = 1/16˝
n Requires minimum 2-1/4˝ n Limits maximum opening. location (2 mm)
(57 mm) minimum top rail Consists of bumper, bumper post, n Consists of clip and mounting
and mounting screw screws

n Requires 4110T-3034H Track
Roller

4110T-3034H
Track Roller
n Quiet, low friction roller assembly
n Shoulder dimension “X” = 1/16˝
(2mm)
n Spring-loaded hold-open
mechanism

B82 LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
