Track Rail Arm Application

D-3550 / D-3551 Series Door Closer Specifications
• T, HT, TCS Application
• Closer mounted on PULL side of door
• Contact dormakaba for Technical Support.
Maximum Door Opening
120° Opening

Hold Open Device 1 2 3
Hold Open Angle 108˚ 87˚ 81˚

Frame

1 2 3 Door

1-11/32” 21-1/32” 1-5/32”
29 mm
23/32” 18 mm 1-5/16” 33 mm Frame
34 mm 534 mm

2-15/16” 74 mm 3-1/32” 77 mm 1/8” 3 mm

5-5/32” 11-15/16” 2-7/16”
131 mm 304 mm 62 mm
Door

8 D-3550/D-3551 Series Door Closers
