Heavy Duty Arm Application
D-3550 / D-3551 Series Door Closer Specifications
• EDA, H-EDA, S, CS, HS and HCS
• Closer mounted on PUSH side of door
• See installation instructions for additional template options.
• Contact dormakaba for Technical Support.

4”
A 102 mm

Frame
5-19/32” 142 mm

13-9/16”
344 mm
Frame

2-15/16” 74 mm 4-31/32” 126 mm

2-7/16”
62 mm 11-15/16”
B 304 mm
Door

D-3550/D-3551 Series Door Closers 7
