Miscellaneous Components

Dummy Touchbar

Rigid Dummy Touchbar – Touchbar is rigid. For push/pull operation
specify Dummy Trim (02 function), see page 5 for Wide Stile and
page 11 for Narrow Stile Trims.
3-0 Door 4-0 Door
Wide Stile: 671DR-3 671DR-4
Narrow Stile: N673DR-3 N673DR-4 End Cap Mounting Bracket
MB305 – Wide Stile
EC992 – Wide Stile
Active Dummy Touchbar with Microswitch – Has an internally
mounted switch that is used to signal electromagnetic locks, horns, NEC993 – Narrow Stile NMB591 – Narrow Stile
monitoring stations or other electronic components. For push/pull For Hinge Stile end of all To mount the device to the
operation specify Dummy Trim (02 function), see page 5 for Wide devices. Specify finish. door on the Hinge Stile side.
Stile and page 11 for Narrow Stile Trims. Available with CD,
ALK, ALW, TDS, DS and NDS options.
3-0 Door 4-0 Door
Wide Stile: TS672DA-3 TS672DA-4 Top Rod – 2200 and FL2200 Series.
Three stock lengths available for 7’-0”, 8’-0”, and 10’-0”
Narrow Stile: TSN674DA-3 TSN674DA-4 high doors.
To Order: specify Device No. x finish (e.g. 672DA-3 x 630) TR1854 – For 7’-0” doors, rod is 36” long.
TR1855 – For 8’-0” doors, rod is 48” long.
Shim Kit - for Narrow Stile Devices TR1857 – For 10’-0” doors, rod is 72” long.
NSMK995 used to accommodate doors TR5197 – For 12’-0” doors, rod is 96” long.
with raised glass moldings. The kit consists Note: 12’-0” top rod is not available in “FL” fire rated option.
of one 1/8” thick shim for the Chassis and
one 1/8” thick shim for the End Cap Bracket For doors of lesser height rods must be field cut. Specify finish (see
Assembly. page 3 for Finish Descriptions).
To Order: Specify NSMK995
(e.g. 2400 NSMK995)
Wide Stile Devices are designed with a 1/4” gap (see Bottom Rod – 2200 and FL2200 Series.
page 2) between the back of the touchbar and the Extended Bottom Rods – For exit device mounting heights
door and do not require shims. If more than 1/4” space greater than 39 15/16 exteded bottom rods are available.
is needed behind the device specify Shim Kit SMK994.
To Order: B5247-09 x finish.
BR1859 – For Touchbar location at 39-15/16” from finished
floor, rod is 32-5/16” long. Specify finish (see page 3 for finish
Descriptions).
Braille Touchbar
FB277 – Fire bolt assembly. (See below)

FB277–
Embossed Touchbar with the message “CAUTION STAIRWELL” in Fire Bolt Assembly
raised letters and Braille provides assistance to persons with impaired
vision. Letters are 5/8” high and Braille is Grade 2, ADA compliant. Strike Hole Plug Transom
To Order: specify suffix “BRL” (e.g. 2103BRL) Frame Bracket
Transom Bracket – 2200 Series.
Miscellaneous TMB453 – To mount the top strike
in the flush transom application. Top
Prepped for S300 Strike. Strike

Dogging Key Rod Guide Door
DK220 – 7/32 standard hex. RG124 – For Surface Vertical Top
Rod Devices. Specify finish. Latch

Apex 2000 Series Touchbar Exit Devices 35
