B660 Deadbolts, B250 Deadlatch , Accessories Schlage

B660 Grade 1 Commercial Deadbolts

Function Mfg # Keyway Finish EZ #
Single Cylinder: Deadbolt thrown or retracted by key outside or
thumbturn inside.
B660P6 605C C Keyway Polished Brass 061952
B660L605 Less Cylinder Polished Brass 080399
B660P6 609C C Keyway Antique Brass 066952
B660P 612 C Keyway Satin Bronze 039606 Schlage
B660P6 626C C Keyway Satin Chrome 061951
B660P6 626C B660L 626 Less Cylinder Satin Chrome 072825
Double Cylinder: Deadbolt thrown or retracted by key either side.
• 1” throw high-strength steel alloy deadbolt with hardened steel roller B662L 626 Less Cylinder Satin Chrome 072826
resists sawing and kick-in attacks. B662P6 605C C Keyway Polished Brass 061954
• Wood frame reinforcer protects wood jamb against kick-in attacks. B662P6 626C C Keyway Satin Chrome 061953
Reinforcer is concealed under strike and is anchored to jamb by two
3” screws. Cylinder by Plate: Deadbolt thrown or retracted by key outside.
• Free-spinning solid cylinder collar resists wrenching and prying. Blank plate with exposed screws inside.
• Large inside thumbturn makes it easy to throw and retract deadbolt. B661P6 626C C Keyway Satin Chrome 039607
• Keying: KD standard, 6 pin cylinder keyed to 5. Classroom: Deadbolt thrown only by key outside; retracted by key
• Metal shield protects bolt from ice-pick attack through door. outside or thumbturn inside.
• Hardened steel balls protect mounting bolts from drill attack. B663P626 C Keyway Satin Chrome 069154

B250 Series Deadlatches B Series Tailpieces & Screws

• Fits doors 1-3/8" to 1-3/4" B202 557
thick. B202 369 B202 558
• “Holdback” feature retains
the deadlatch in a retract-
ed position when desired.
• ANSI A156.5 Grade 1. B220 036 B220 177
• Stocked 2 3/4” backset with
“C” keyway Mfg # Description Series EZ #
B250PD6 613
• Keying: KD standard, 6 pin Stocked in 626 (Satin Chrome) B202 369 1 5/8”, 1 3/4”, 3” Standard Tailpiece B252, B462 012161
cylinder keyed to 5. B202 557 Standard Tailpiece 1-27/32” B160 012164

Mfg # Keyway Finish EZ # B202 558 Standard Tailpiece2” B160 012165
Single Cylinder B220 036 2” to 2-1/4” Door B162 012167
B250PD6 605C 2 3/4 C Keyway Polished Brass 037071 B220 177 1-3/8” to 1-3/4” Screw & Tailpiece 626 BC160P 074485
B250PD6 626C 2 3/4 C Keyway Satin Chrome 037072 B520 087 652 1-15/16” to 2-1/4” Door Long Screws 626 B250 037141
Double Cylinder B610 046 2”-2-1/2” Tailpiece 662 031152
B252PD6 605C 2 3/4 C Keyway Polished Brass 037074 XB11 990 2” - 2/1/4” Tailpiece & Screw Kit BC160 077736
B252PD6 626C 2 3/4 C Keyway Satin Chrome 037073 E205 204 2-1/4” Tailpiece B160N 012300

207
