Schlage A Series Grade 2 Knob Sets & Latches

A Series Grade 2 Knob Sets

Tulip
• Symbol: TUL
Orbit
• Symbol: ORB • Knob: 2" diameter
• Knob: 2-1/8" diameter • Rose: 2-9/16" diameter
• Rose: 2-9/16" diameter • Projection: 2-5/8"
• Projection: 2-7/8"
Schlage • Heavy duty residential, me- • Latch: 1/2" throw brass
dium duty commercial.
chrome plated deadlatch,
A53PD ORB 605 • ANSI A156.2 Series 4000 3/8" throw springlatch.
Grade 2. U.L. listed. • Chassis: steel, zinc dichro-
Mfg # Cylinder Design Finish EZ # • Keying: KD standard, 6 pin mate plated for corrosion
cylinder keyed to 5. resistance.
Passage Function: Both knobs always unlocked
• Door Range: 1-3/8" to 1-7/8" • Trim: Wrought brass, bronze
A10S ORB605 2 3/4 Orbit Polished Brass 037036 standard. or stainless steel.
A10S ORB626 2 3/4 Orbit Satin Chrome 027454 • Backset: 2-3/4", 2-3/8” • Strike: T-strike 1-1/8˝ x 2-3/4˝
A10S TUL626 2 3/4 Tulip Satin Chrome 027462 • Latch Front: Steel. 1-1/8˝ x 2-
1/4˝ square corner beveled
Exit Function: Blank plate outside. Inside knob always unlocked
A25D ORB 626 23/4 Orbit Satin Chrome 039571
Privacy Function: Push button locking. Can be opened from outside
with small screwdriver. Turning inside knob or closing door releases
button. A Series Latches &
A40S ORB626 2 3/4 Orbit Satin Chrome 027468 Extension Links
Entrance Function:Turn/push-button locking; pushing and turning
button locks outside knob requiring use of key until button is man-
ually unlocked. Push-button locking; pushing button locks outside
knob until unlocked by key or by turning inside knob.

A53LD ORB626 2 3/4 Less Cylinder Orbit Satin Chrome 027475
A53PD ORB 605 2 3/4 C Keyway Orbit Polished Brass 037039
A53PD ORB 612 23/4 C Keyway Orbit Satin Bronze 039587 11 096
11 068
A53PD ORB 613 2 3/4 C Keyway Orbit Oil Rubbed Bronze 037040
41-005
A53PD ORB 626 2 3/4 C Keyway Orbit Satin Chrome 037041 • Extension link when used
A53PD TUL 626 2 3/4 C Keyway Tulip Satin Chrome 037044 with a 2-3/8” latch (not
Classroom Function: Outside knob locked and unlocked by key. included) creates a 5”
Inside knob always unlocked. backset latch.
A70LD ORB 626 2 3/4 Less Cylinder Orbit Satin Chrome 037309
Mfg # Finish Backset Dia. Type EZ #
A70PD ORB 626 2 3/4 C Keyway Orbit Satin Chrome 037310 11 068 626 626 2-3/8” 7/8” Spring 012683
Storeroom Function: Outside knob always fixed. Entrance by key 11 085 626 626 2-3/8” 7/8” Deadlatch 012687
only. Inside knob always free for exit.
11 096 605 605 2-3/4” 1” Deadlatch 012690
A80LD ORB 605 2 3/4 Less Cylinder Orbit Polished Brass 037051
11 096 626 626 2-3/4” 1” Deadlatch 012693
A80LD ORB 626 2 3/4 Less Cylinder Orbit Satin Chrome 037048
11 103 626 626 3-3/4” 1” Deadlatch 073780
A80PD ORB 605 2 3/4 C Keyway Orbit Polished Brass 037052
41 005 Zinc 5” Extension 013150
A80PD ORB 626 2 3/4 C Keyway Orbit Satin Chrome 037053

202
