QDB
MECHANICAL LOCKS 200 Series Grade 2
Standard-Duty Auxiliary Deadbolts

Performance Features

• Tested to meet Grade 2 specification of 150,000 cycles.
• Full 1" (25.4mm) throwbolt with saw-resistant hardened steel roller pin.
• Free-spinning cylinder collar prevents against wrench attacks.
• Anti-drill design – Two (2) ball bearings inserted to prevent drill attacks.
• ADA thumbturn.
• Compartmentalized packaging allows for quick and easy installation.
• Available with SmartKey Technology.
Single Cylinder Double Cylinder

Certifications

• ANSI/BHMA A156.12 – 1999 Grade 2
• ANSI A117.1 Accessibility Code (ADA Compliant)
• UL/cUL Listed (3 hours) for “A” label single-door applications
(4' x 8') (1.219m x 2.438m)
• UL10C/UBC 7-2 (1997) Positive Pressure Rated
• UL10B Pressure Rated
• Hurricane Compliant – Miami-DADE N.O.A. See page 72 for more details. QDB285 Indicator QDB288 Key Control

Product Specifications

• Door range – 1 ⁄8" (35mm) to 2"(51 mm).
3
3
Service part number 8Q00082 spacer rings required for 1 ⁄8" doors. Functions
• Backset – 2 ⁄4" (70mm) square standard. 2 ⁄8" (60mm) available.
3
3
• Exposed trim – Stainless steel with iron forged cylinder guard. ANSI Series Description
• Strike – Standard deadbolt strike 1 ⁄8" x 2 ⁄4" (32mm x 70mm). E0152 QDB280 Single Cylinder
1
3
Other strike options also available.
E0152 QDB281 Single Cylinder SFIC
• Latch bolt – Full 1" (25.4mm) throw with hardened steel roller.
E0142 QDB282 Double Cylinder
• Faceplate – 1 ⁄8" x 2 ⁄4" (29mm x 57mm) standard.
1
1
1" x 2 ⁄4" (25.4mm x 57mm) faceplate available. E0142 QDB283 Double Cylinder SFIC
1
E0193 QDB284 Inside Turnbolt
— QDB285 Indicator
Keying E0172 QDB286 Classroom
E0172 QDB287 Classroom SFIC
• 6-pin non-IC brass cylinders. 6 or 7 pin SFIC option available. Many keying options E0152 QDB288 Key Control
available from our factory to include, but not limited to, master keying, grand
master keying and construction keying. Small format interchangeable core
cylinder also available.
• 2 keys per lockset.
• Offered with the following keyway options: SMT-SmartKey, KW-Kwikset, WE-Weiser, Finishes
SC-Schlage, GA-Yale, LA-Sargent, BF-BEST "F" SFIC, & LC-Less Cylinder.
BHMA Description
605 Bright Brass
Warranty 613 Oil Rubbed Bronze
619 Satin Nickel
• Lifetime Mechanical and 3-year finish*
625 Bright Chrome
*(613/US10B carries no finish warranty)
626 Satin Chrome

34 Stanley Commercial Hardware
