QDB
100 Series Grade 1
Heavy-Duty Auxiliary Deadbolts

Performance Features

• Tested to meet Grade 1 specification of 250,000 cycles.
• Solid forged housing provides enhanced strength and durability.
• Full 1" (25.4mm) throwbolt with saw-resistant hardened steel roller pin.
• Anti-drill design – two (2) ball bearings inserted to prevent drill attacks.
• ADA thumbturn.
• Compartmentalized packaging allows for quick and easy installation.

Single Cylinder
Certifications

• ANSI/BHMA A156.5 Series – Grade 1
• ANSI A117.1 Accessibility Code (ADA Compliant) MECHANICAL LOCKS
• UL/cUL Listed (3 hours) for “A” label single-door applications
(4' x 8') (1.219m x 2.438m)
• UL10C/UBC 7-2 (1997) Positive Pressure Rated
• UL10B Pressure Rated
• California State Reference Code (formerly Title 19 – Fire Marshal)
• Hurricane Compliant – Miami-DADE N.O.A. See page 72 for more details.
Double Cylinder

Product Specifications
Functions
• Door range – 1 ⁄8" (35 mm) to 2" (51 mm).
3
3
Service part number 8Q00082 spacer rings required for 1 ⁄8" doors.
• Backset – 2 ⁄4" (70mm) square standard. ANSI Series Description
3
2 ⁄8" (60mm) available. E0151 QDB180 Single Cylinder
3
• Exposed trim – Solid forged brass, plated to match finish designation. E0151 QDB181 Single Cylinder SFIC
3
1
• Strike – Standard deadbolt strike 1 ⁄8" x 2 ⁄4" (32mm x 70mm). E0141 QDB182 Double Cylinder
Other strike options also available.
E0141 QDB183 Double Cylinder SFIC
• Door prep – 2 ⁄8" (54mm) diameter cross bore.
1
• Latch bolt – Full 1" (25.4mm) throw with hardened steel roller; E0171 QDB186 Classroom
Faceplate – 1 ⁄8" x 2 ⁄4" (29mm x 57mm). E0171 QDB187 Classroom SFIC
1
1
Keying
Finishes
• 6-pin non-IC brass cylinders. 6 or 7 pin SFIC option available. Many keying options
available from our factory to include, but not limited to, master keying, grand
master keying and construction keying. Small format interchangeable core BHMA Description
cylinder also available. 605 Bright Brass
• 2 keys per lockset. 613 Oil Rubbed Bronze
• Offered with the following keyway options: KW-Kwikset, WE-Weiser, SC-Schlage, 619 Satin Nickel
GA-Yale, LA-Sargent, BF-BEST "F" SFIC, & LC-Less Cylinder.
625 Bright Chrome
626 Satin Chrome
Warranty

• Lifetime Mechanical and 3-year finish*
*(613/US10B carries no finish warranty)

Stanley Commercial Hardware 31
