Cores, IC cylinders and parts

Full size core
Full size interchangeable cores - options
• Conventional core
• Primus XP high security core

Available in 606 and 626 finish only. Everest 29 S123 keyway
standard for commercial; C keyway standard for residential.

IC cylinders for deadbolt (top) - options
Tailpiece not included. Low, 10-32 Bolts

• Housing less core
• Housing with conventional core
• Housing with Primus core
Driver and retainer for
IC knob
Available in 605, 606, 609, 610, 611, 612, 613, 616, 625, 626. 01-053
Everest 29 S123 keyway standard for commercial;
C keyway standard for residential.

IC installation tool M504-413

This tool is used to install the driver and retainer for full size IC in
Schlage knobs and levers. Its other ends are designed to install and
remove mortise cylinder housings and test mortise cylinder cam action
for both small format and full size interchangeable core cylinders.
