General
information
Specifications
h) Provisions in the control box or module shall provide 2.12 HARDWARE FINISHES
control {inputs and outputs} for; electric strike delay, A. Finish
auxiliary contact, sequential operations, fire alarm 1. All closers with powder coat finishes shall exceed a minimum
systems, actuators, swing side sensors, stop side sensors. 100 hour salt spray test, as described in ANSI/BHMA Standard
[2610, 4630, 4640, 4810, 4820, 4840, 9130, 9140, A156.4 and ASTM B117.
9150 Series] 2. All closers detailed with plated finishes shall include plated
covers (or finish plates), arms, and visible fasteners.
5. [4630, 4640 Series] All electrohydraulic automatic 3. All electromechanical automatic operators supplied
operators shall include the following features or functions: with anodized finishes.
a) Second Chance Feature: When an obstruction or 4. All closers must be shipped with a finish.
resistance to the opening swing is encountered the
operator will pause at that point, then attempt to PART 3 - EXECUTION
continue opening the door. If the obstruction or resistance 3.1 INSTALLATION
remains, the operator will again pause the door. A. General
b) Easily accessible main power and maintain hold-open 1. Installation shall be in accordance with the templates and
switches will be provided on the operator. installation instructions packaged with the closers
c) An electronically controlled clutch to provide adjustable at the time of manufacture.
opening force. 2. Installation shall be made with fasteners packaged with the
d) A microprocessor to control all motor and clutch closer by the manufacturer.
functions. 3. All electrical connections shall be made in accordance with the
e) An on-board power supply capable of delivering both 12V manufacturers recommendations.
and 24V outputs up to a maximum of 4. Clean installed closer to remove dirt, debris, and marks
1.0 ampere combined load. incidental to installation work.
f) All input and output power wiring shall be 5. Installation instructions and templates are to be turned over to
protected by a resettable circuit breaker. the Owners representative upon completion of the installation
work.
-Or- 6. Factory trained representative will be available for job site
inspection of major projects upon completion of the hardware
5. All electromechanical automatic operators shall include the installation work.
following features of functions:
a) Maximum 8-1/2 lbs of manual opening force [9130, 3.2 ADJUSTMENT
9140, 9150 Series]. A. Adjustment
b) Maximum 15 lbs of manual opening force [2810, 2850, 1. Install and regulate all closers in accordance with the
2860, 9530, 9540, 9550, 9560 Series]. installation instructions packaged with the closers at the time
c) Bottom loaded header for easy access to controls [2810, of manufacture.
2850, 2860, 9550, 9560 Series]. 2. If unfamiliar with LCN products furnished, consult factory
d) Power Boost, which adds an additional 25 lbs of closing representative prior to installation for assistance.
force at latch [2810, 2850, 2860, 9130, 9140, 9150,
9530, 9540, 9550, 9560 Series].
e) Self contained automatic operators in a cast aluminum
housing and a forged steel arm [2810, 2850, 2860,
9130, 9140, 9150, 9530, 9540, 9550, 9560 Series].
