General
information

HEADER – Aluminum enclosure for motor gearbox & J Glossary of terms
controller. JAMB – The vertical member that forms the sides of a door
HINGE SIDE – Face of door and frame on which the hinge frame. There is a hinge side jamb and a strike side jamb.
pivot point is located. H- M
HINGE SIDE MOUNT – Mounting with the closer cylinder on L
LABELED DOOR – Conforms to all applicable codes,
the hinge side of the door top rail.
requirements, and procedures governing fire rated doors and
bears the manufacturer’s identification label.
HINGE (PULL) LATCH SPEED – Separate adjustment to control the last few
SIDE MOUNT degrees of the door’s closing swing.

LATCH SPEED
LATCH SPEED REGULATION

HINGE SIDE REVEAL – Depth measured from the frame face
to the pull side of the door face.

HINGE SIDE REVEAL LOCK STILE – Vertical member of a door prepared for
installation of a lock.
LONG ARM (LONG) – Extended arm for deep reveals or other
special applications.
LOW ENERGY OPERATOR – A type of automated opener
used on a door that should take approximately 5 seconds to
HINGE STILE – Vertical member of a door prepared for open to 90°. Low Energy operators do not require safety devices
installation of hinges. or guide rails. Conforms to ANSI A156.19.
HOLD-OPEN ARM (H) – Double lever arm that provides hold- M
open function that is either adjustable at elbow or shoe.
MAIN ARM – Connects to the cylinder in a double lever arm
HOLD-OPEN CLIP – Located in track to provide hold-open system.
function for single lever arms.
MAIN SPEED – Separate adjustment to control closing swing
HOLD-OPEN CUSH (HCUSH) – Parallel arm that features of the door to within a few degrees of latch.
solid forged steel main arm and forearm with stop in soffit
shoe. Uses control handle to select hold-open function. MAIN SPEED
MAIN SPEED REGULATION
HOLD-OPEN LONG ARM (HLONG) – Hold-open arm
extended by a long head and tube for deep reveals.
HOLD-OPEN TRACK with BUMPER (HBUMPER) –
Track with hold-open clip and bumper assembly installed.
HOLDER SCANNER-ACTIVATED (HSA) – Electrically
controlled closer/holder with built-in scanner.
HYDRAULIC FLUID – Fluid metered by valve system to control MAXIMUM OPENING – Furthest degree of door opening.
door.
METAL COVER (MC) – Stamped metal cover required for
I optional plated finishes and custom powder coat finishes.
Standard cover with High Security Series closers.
INDEPENDENT PAIR – Two automatic doors that function
separately. MOTOR CLUTCH – The geared assembly in an LCN electric
power operator. Once activated, the motor clutch drives the
door open.
MOTOR GEARBOX – Electromechanical drive unit.

LCN Door Control Catalog A27
