General
information

Glossary of terms EXTRA DUTY ARM (EDA) – Double lever arm with both main FLUSH PANEL ADAPTER – Adapter provides PA shoe mounting
and forearm made of solid forged steel for extra strength. surface when door and frame are flush.
EXTRA-DUTY ARM FLUSH
E - H PANEL
ADAPTER

FOREARM – Arm part that connects main arm to the shoe
EXTRA LONG ARM (XLONG) – 4040XP Series double lever attachments in a double lever arm system.
arm for exceptionally deep reveals or other special applications. FRAME DEPTH – Face to face dimension of the frame.
F FRAME FACE – Exposed part of frame parallel to face of
the wall.
®
™
(LCN ) FAST POWER ADJUST – A green dial located on
the end of the spring tube on selected heavy duty closers. FRAME FACE
Designed to help installers accurately adjust the closer power
to match the conditions of the entrance.
®
™
LCN FAST POWER ADJUST

FULL COMPLIMENT BEARINGS – Low friction, high load needle
bearings found in all LCN closers.
FIFTH SCREW – Mounting screw farthest from the door on a FULL COVER (FC) – Cover that encloses cylinder assembly
parallel arm shoe. except for shaft/arm attachment.
FIFTH SCREW SPACER – Supports PA shoe mounted on FUSIBLE LINK ARM (FL) – Releases hold-open function when
frame stop. exposed to high temperatures. 135°F and 165°F available.
FINISH PLATE – Decorative plate applied to overhead
concealed closer to conceal closer mounting plate and screws. FUSIBLE LINK ARM
FIRE SHIELD – 22-gage steel liner mounts in the track mortise
of the door’s top rail for 20 minute labeled wood doors.
FLUSH CEILING – Condition when the ceiling is at the same
height as the top of the frame.

FLUSH CEILING
H
HAND – Direction of a doors’ swing, either right or left.
HAND

HANDED – Closer or part designed for ONLY right or left
swinging doors.
HEAD FRAME – Member of the frame above the door.

A26 LCN Door Control Catalog
