P. 15
QTL
MECHANICAL LOCKS 200 Series Grade 2
Standard-Duty Tubular Locks
Performance Features
• Tested to meet Grade 2 specification of 400,000 cycles.
• Heavy-duty torsion springs provide longer performance life and prevent
lever sag.
• Concealed mounting screws.
• “Anti-Lockout” feature. The entry function will have a free interior. If the
door is locked from the inside, it will unlock with the push of the interior Sierra (E)
side of the lever only or the turn of the button.
• 1/2" (13mm) latch bolt made of stainless steel black powder metallurgy for
enhanced durability and strength.
• Compartmentalized packaging allows for quick and easy installation.
Certifications
Summit (M)
• ANSI/BHMA A156.2 Series – Grade 2
• ANSI A117.1 Accessibility Code (ADA Compliant)
• UL/cUL Listed (3 hours) for “A” label single-door applications
(4' x 8') (1.219m x 2.438m)
• UL10C/UBC 7-2 (1997) Positive Pressure Rated
• UL10B Pressure Rated
• California State Reference Code (formerly Title 19 – Fire Marshal)
• Hurricane Compliant – Miami-DADE N.O.A. See page 72 for more details.
Slate (A)
Product Specifications
Functions
• Handing – All QTL200 Series Levers Locksets are non-handed.
• Door thickness – 1 ⁄8" - 1 ⁄4" (35mm-51mm) standard.
3
3
ANSI Series Description
• Backset – Universal backset standard, will fit either 2 ⁄8" or 2 ⁄4" backsets
3
3
(60mm-70mm). — QTL220 Single Dummy
• Exposed trim – Pressure cast zinc, plated to match finish designation. F75 QTL230 Passage
• Strike – Full-lip strike standard (57mm x 44.4mm). F76B QTL240 Privacy
Other strike options also available. F82 QTL250 Entry/Office
• Latch bolt – ⁄2" (13mm) steel throw.
1
F82 QTL251 Entry/Office SFIC
• Latch faceplate – 1" x 2 ⁄4" (25.4mm x 57mm) standard.
1
F84 QTL260 Classroom
F84 QTL261 Classroom SFIC
F86 QTL270 Storeroom
Keying F86 QTL271 Storeroom SFIC
• 6-pin non-IC brass cylinders. 6 or 7 pin SFIC option available. Many keying options
available from our factory to include, but not limited to, master keying, grand master Finishes
keying and construction keying.
• 2 keys per lockset.
• Offered with the following keyway options: BF-BEST "F" SFIC, KW-Kwikset, WE-Weiser, BHMA Description
SC-Schlage, GA-Yale, LA-Sargent, & LC-Less Cylinder. 605 Bright Brass
Consult factory for other cylinder options. 613 Oil Rubbed Bronze
Warranty 619 Satin Nickel
625 Bright Chrome
• Lifetime Mechanical and 3-year finish* 626 Satin Chrome
*(613/US10B carries no finish warranty)
28 Stanley Commercial Hardware
