QCI
200 Series Grade 2
Standard-Duty Interconnected Locks

Applications

The QCI200 Series Interconnected Levers are designed for multi-family,
assisted living, commercial & mixed-use applications where single motion
egress is required. These levers deliver premium performance and are
designed to withstand the physical abuses of the applied environment.

Performance Features

• Tested to meet Grade 2 specification of 400,000 cycles.
• Single-motion egress provides easy emergency exit. Sierra (E) – Single-Locking
• Full 1" (25mm) throwbolt with saw-resistant hardened steel roller pin.
• Anti-drill design deadbolt – two (2) ball bearings inserted to prevent drill attacks.
• ADA thumbturn.
• Tapered latch bolt to address warped door concerns.

Certifications MECHANICAL LOCKS

• ANSI/BHMA A156.12 – 1999 Grade 2
• UL/cUL Listed (3 hours) for “A” label single-door applications (4' x 8')
(1.219m x 2.438m)
• UL10C/UBC 7-2 (1997) Positive Pressure Rated Summit (M) – Double-Locking
• UL10B Pressure Rated
• ANSI A117.1 Accessibility Code (ADA Compliant)

Product Specifications

• Door range – 1 ⁄8" - 1 ⁄4" (35mm-44.5mm).
3
3
• Heavy-duty cylindrical lock body.
• 4" center-to-center.
3
3
• Backset – 2 ⁄4" (70 mm) standard. 2 ⁄8" (60mm) available.
• Exposed trim – Wrought brass or bronze with cast zinc lever.
• Strikes – “T” strike 1 ⁄8" x 2 ⁄4” standard for lever, Slate (A) – Indicator
1
3
1
3
deadbolt strike 1 ⁄8" x 2 ⁄4" standard. Other strike options also available.
• Latch bolt – Keyed ⁄2" (13mm) steel throw with auxiliary latch, Functions
1
passage ⁄2" (13mm) spring latch.
1
• Handing – All QCI200 locksets are non-handed. ANSI Series Description
1
• Standard door prep: 2 ⁄8" cross bore (54mm).
• Latch hole – 1" diameter edge bore. F95 QCI230 Single-Locking (Passage Lever)
F95 QCI231 Single-Locking SFIC (Passage Lever)
• Rose diameter – 2 ⁄2" (63mm).
1
• Inside escutcheon – 3" x 8" (82.5mm x 203mm). F97 QCI250 Double-Locking (Entry Lever)
Optional exterior escutcheon – 3 ⁄4" x 8" (82.5mm x 203mm). F97 QCI251 Double-Locking SFIC (Entry Lever)
1
— QCI285 Indicator (Passage Lever)
Keying
• 6-pin non-IC brass cylinders. 6 or 7 pin SFIC option available. Many keying options
available from our factory to include, but not limited to, master keying, grand Finishes
master keying and construction keying. Small format interchangeable core
cylinder also available.
• 2 keys per lockset. BHMA Description
• Offered with the following keyway options: SMT-SmartKey, KW-Kwikset, WE-Weiser, 605 Bright Brass
SC-Schlage, GA-Yale, LA-Sargent, BF-BEST "F" SFIC, & LC-Less Cylinder. 613 Oil Rubbed Bronze
619 Satin Nickel
Warranty 626 Satin Chrome
• Lifetime Mechanical, 3-year finish* and 1-year electrical *(613/US10B carries no finish warranty)

Stanley Commercial Hardware 25
