4020T
Series

How-to-order 4020T Series closers Ordering Information
Closer will be shipped with:
1. Select cylinder size 3. Select finish -Standard cylinder
4021T (ADA) Standard Powder Coat __________ - Standard cover
4023T Aluminum, Dark Bronze, Statuary, - Standard arm
4024T Light Bronze, Black, Brass. - Track roller
2. Specify hand - Standard track
RH - Self-reaming and tapping screws
LH unless options listed below are selected.

Closer options

Cover Screw Pack
Metal (MC) TB* & SRT Screw (TBSRT)
Track Wood & Machine Screw (WMS)
Standard with Bumper (BUMPER) TB*, Wood & Machine Screw
Hold-Open (HO) (TBWMS)
Hold-Open with Bumper (HBUMPER) TORX Machine Screw (TORX)
TB* & TORX Machine Screw (TBTRX)
Finish * Specify door thickness if other than
Custom Powder Coat (RAL) __________ 1-3/4˝
(handed metal cover required) Installation Accessories
Plated Finish, US _____________ Plate, 4010T-18
(handed metal cover required) Special Template
SRI primer (use with powder coat ST- _________
finishes only)

Table of sizes
n Select closer based on width of door
n 4020T Series cylinders available in size 1, 3 or 4
n Closing power of all 4020T Series closers may be increased 15%
n Specify next higher size closer where strong drafts exist

Interior door width

26˝ 34˝ 38˝ 48˝
660mm 864mm 965mm 1219mm
size 1 size 3 size 4
4021T *
4023T
4024T

Minimum door width

Indicates recommended range of door width for closer size.

LCN Door Control Catalog B21
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
