General
information

Mechanical
considerations

DOOR DIMENSIONS? HAND OF A DOOR?
The width of the door is the main consideration in determining Some door closers are handed. When approaching a door from
the correct closer size. Size here refers to the minimum spring the push side, if hinged on the left, it is a left hand door; if hinged
power and hence the closing force, generated by the closer. In on the right, it is a right hand door.
the catalog, the interior and exterior TABLE OF SIZES for each
closer are set up for ranges of door width and assume normal
operating conditions. If a door is of exceptional height, weight,
special construction, or if drafts and air pressure differ entials exist,
increased closer power should be considered.

Door thickness may be a factor. A concealed-in-the-door closer
should not be used in a hollow metal door less than 1-1/2˝ (38
mm) thick or a wood door under 1-3/4˝ (44 mm). Exceptionally For purposes of handing door closers, right hand reverse bevel and
thick doors can affect hinge and pivot centers to the extent that left hand are identical. Also, left hand reverse bevel and right hand
closer functions and geometry are also affected. are identical.

The depth of the doors top rail is important to nearly every closer WILL A STANDARD CLOSER AND TEMPLATE MEET
installation. Narrow top rails may require plates to successfully YOUR NEEDS?
mount the closer. An insufficient top rail in flush, hollow, or Occasionally the physical limitations of the selected closer may
composite filled doors may make concealed-in-the-door not provide the desired functions or degree of opening. Standard
installations impractical. templated locations may interfere with other applied hardware.
In these situations, contact the LCN Applications Engineering
DOOR TOP RAIL Department for assistance. Customized installation templates or
pro ducts may be available to solve an unusual application.

LCN Door Control Catalog A19
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
