Electric Strikes

0 Series
0563 1/2" Rim Strikes

Slim, adjustable design ideal for tight-fitting installations. Designed for use with Pullman latch rim exit devices.
1-3/4"W x 9"H x 1/2"D (45mm x 229mm x 13mm)
Energy Strength ELECTRIC STRIKES
19mA 1,500lbf Static Endurance
1
Auto-Sensing 70ft-lb Dynamic 100,000 Cycles
12-24VDC
Mode Monitoring Warranty
Field-Selectable Optional Latch Monitor 5 Year Limited Warranty
Fail-Safe & Fail-Secure Model Available
1 Steady state current at 12VDC, 153mA peak
• Surface-mounted – no frame cutting required
• Accommodates 1/2" to 3/4" (13mm–19mm) latch projection
• Includes two 1/8" (3.2mm) spacers to create two additional sizes, 5/8" (16mm) & 3/4" (19mm)
• Horizontal adjustment ensure proper latch positioning to compensate for door misalignment – up to 1/4" (6.4mm)
• Conventional keeper design (one moving part) – promotes even load distribution
• Lockdown holes for secure mount
• Low energy: draws less energy than traditional solenoid strikes
• Cost savings: operate 3X more strikes per power supply
• Cooler operation – runs cool to the touch; no suppressor kit needed
• High-grade stainless steel ensures superior strength and creates a sleek aesthetic
• Non-handed
• Plug-in wire connectors
• Brushed Stainless Steel (32D) finish
• UL 1034 burglary-resistant Listed
• Patent pending

Options
• LM – Latch monitor

Conventional Keeper Lockdown Holes Latch Monitor
(One Moving Part) For Secure Mount (0563LM Model)

How To Order
0563 x 32D
LM – Latch Monitor
Options
Example: 0563LM x 32D

Accessories
Model Description
0162DDH Double door housing, SPC finish
2
0162MSK 1/16" (1.5mm) mounting spacer
Note: Maximum voltage must not exceed 28V. Overheated or burnt PCBs caused by incorrect input voltage will not be covered under warranty.
UL 1034 Burglary-resistant listing does not apply with use of 0563DDH.
3 SPC=Silver Powder Coat
